Air Cooler Pump

PREV：No previous article NEXT：Industrial Air Cooler Pump

Specification
Applications
Parameters
Contact Us

Features:
1.Sealed resin potting provides excellent insulation,preventing safety hazards.
2.Built-in heat-protector prevents power failure due to continuous dry burning caused by water shortage.
3.The outer shell is made of new ABS plastic,ensuring durability.
4.The shaft is made of high-quality ceramic,long lifespan,corrosion-resistant and wear-resistant.5.The bottom suction cup easily adheres to flat surfaces and is not easily detached,resulting in quiet operation.

Can be customized according to requirements.

Applications:
Water-cooled electrical equipment such as evaporative air conditioners,air conditioners,misting fans,eco-friendly air conditioners,and mechanical cooling
systems.

	Item	Parameter
	MODEL	DYH‑8
	WATTS	8W
	MAX HEAD	1M/1.2M/1.3M
	MAX FLOW	300L/Ha
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	627572mm
	OUTLET DIAMETER	φ13mma

	Item	Parameter
	MODEL	DYH‑8
	WATTS	8W
	MAX HEAD	0.8M/1M/1.2M/1.3M
	MAX FLOW	300L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	624772mm
	OUTLET DIAMETER	φ9mm

	Item	Parameter
	MODEL	DYH‑8
	WATTS	8W
	MAX HEAD	0.8M/1M/1.2M/1.3M
	MAX FLOW	300L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	62.546.577mm
	OUTLET DIAMETER	φ9mm

	Item	Parameter
	MODEL	DYH‑16B
	WATTS	16W
	MAX HEAD	1.2M/1.4M/1.5M/1.6M
	MAX FLOW	900L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	718390mm
	OUTLET DIAMETER	φ9/13mm

	Item	Parameter
	MODEL	DYH‑16
	WATTS	16W
	MAX HEAD	1.2M/1.4M/1.5M/1.6M
	MAX FLOW	900L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	71×53.7×90mm
	OUTLET DIAMETER	φ9/13mm

Item	DYH‑18B	DYH‑25B
MODEL	DYH‑18B	DYH‑25B
WATTS	18W	25W
MAX HEAD	1.6M/1.8M/2M/2.2M	1.6M/1.8M/2M/2.2M
MAX FLOW	1000L/H	1500L/H
VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
SIZE	75×78×90mm	75×78×90mm
OUTLET DIAMETER	φ9/13/19mm	φ9/13/19mm

Item	DYH‑18	DYH‑25
MODEL	DYH‑18	DYH‑25
WATTS	18W	25W
MAX HEAD	1.6M/1.8M/2M/2.2M	1.6M/1.8M/2M/2.2M
MAX FLOW	1000L/H	1500L/H
VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
SIZE	75×50×90mm	75×50×90mm
OUTLET DIAMETER	φ9/13/19mm	φ9/13/19mm

Item	DYH‑22	DYH‑30
MODEL	DYH‑22	DYH‑30
WATTS	22W	30W
MAX HEAD	2M	2.3M
MAX FLOW	1200L/H	1500L/H
VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
SIZE	90×62×102mm	90×62×102mm
OUTLET DIAMETER	φ13/16/19/21mm	φ13/16/19/21mm

	Item	DYH‑25
	MODEL	DYH‑25
	WATTS	25W/22W
	MAX HEAD	1.8M/2M/2.2M
	MAX FLOW	1500L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	90×84×82mm
	OUTLET DIAMETER	φ9/13mm

	Item	DYH‑8
	MODEL	DYH‑8
	WATTS	8W
	MAX HEAD	1M/1.2M/1.3M
	MAX FLOW	300L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	63×74.3×80.6mm
	OUTLET DIAMETER	φ13mm

	Item	DYH‑16
	MODEL	DYH‑16
	WATTS	16W
	MAX HEAD	1.6M
	MAX FLOW	900L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	71×54×90mm
	OUTLET DIAMETER	φ13mm

	Item	DYH‑16B
	MODEL	DYH‑16B
	WATTS	16W
	MAX HEAD	1.6M
	MAX FLOW	900L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	71×80×90mm
	OUTLET DIAMETER	φ13mm

	Item	DYH‑18
	MODEL	DYH‑18
	WATTS	18W
	MAX HEAD	1.8M
	MAX FLOW	1000L/H
	VOLTAGE/FREQUENCY	AC 12‑24V/110V‑120V/127V/220V‑240V, 50Hz/60Hz
	SIZE	79×61×105mm
	OUTLET DIAMETER	φ13mm
